Cisco WS-C3750-48TS-S Layer 3 Switch - 48 x 10/100.


THÔNG TIN CHI TIẾT SẢN PHẨM
Bảo hành 12 Tháng
Trong kho Có hàng
Tình trạng Mới 95%
Cisco WS-C3750-48TS-S Network & Communication

Number of Stacks: 9
Address Table: 12K MAC Addresses
Cisco WS-C3750-48TS-S Management & Protocols

Manageable: Yes
Cisco WS-C3750-48TS-S Environmental Conditions

Humidity: 10% to 85% Non-condensing Relative Humidity Operating
Altitude: 15000 ft Maximum Storage
Altitude: 10000 ft Maximum Operating
Thermal Dissipation: 205BTU/h
Cisco WS-C3750-48TS-S Media & Performance

Performance: 13.1Mpps Forwarding Rate
Cisco WS-C3750-48TS-S I/O Expansions

Number of Expansion Slots: 4
Expansion Slots: (4 Total) SFP (mini-GBIC) Uplink
Modules: Not Included
Cisco WS-C3750-48TS-S Network & Communication

Flow Control: IEEE 802.3x (Full-duplex)
Layer Support: 2 to 3
Cisco WS-C3750-48TS-S Miscellaneous

Additional Information:

• Up to 12 EtherChannel groups are supported per stack

• Up to 64 aggregate or individual policers are available per Fast Ethernet or Gigabit Ethernet port

• 11,000 unicast routes

• Configurable up to 1000 IGMP groups and multicast routes

• Configurable maximum transmission unit (MTU) of up to 9018 bytes (Jumbo frames) for bridging on Gigabit Ethernet ports, and up to 1546 bytes for bridging and routing on Fast Ethernet ports

• Acoustic noise: 42 decibels (dB)

Cisco WS-C3750-48TS-S Management & Protocols

Management:

• Command-line interface (CLI)

• Cisco Cluster Management Suite (CMS) Software

• CiscoWorks

• IGMP snooping

• Up to 1024 VLANs per switch or stack and up to 128 spanning-tree instances per switch are supported

• 4000 VLAN IDs are supported

• Cisco Group Management Protocol (CGMP)

• RMON

• Trivial File Transfer Protocol (TFTP)

• Web browser setup utility allows one-click initialization for IP addresses and passwords

• SNMP v1, v2c, and v3

Protocols: HSRP
Protocols: CDPv2
Protocols: DVMRP
Protocols: DTP
Protocols: DHCP
Protocols: PAgP
Protocols: LACP
Protocols: CDPv1
Protocols: TCP/IP
Protocols: VTP
Protocols: ARP
Protocols: RIP v1.0
Protocols: Spanning Tree Protocol
Protocols: MSTP
Protocols: RIP v2.0
Security Features:

• RADIUS

• TACACS+

• SSH

• VLANs

• 1000 access control entries (ACEs) are supported

• Authentication

• Port-level security

• Identity-based network services with 802.1x and extensions

Cisco WS-C3750-48TS-S Memory

Standard Memory: 128MB
Flash Memory: 16MB
Cisco WS-C3750-48TS-S Software

Operating System:

• Software Image: Standard Multilayer Image (SMI)

Cisco WS-C3750-48TS-S Controls/Indicators

Status Indicators: Per-port status LEDs:

• Link integrity

• Disabled

• Activity

• Speed

• Full-duplex indications

System-status LEDs:

• System

• RPS

• Bandwidth-utilization indications

Cisco WS-C3750-48TS-S Reliability

MTBF: 217824Hour
Cisco WS-C3750-48TS-S Power Description

Input Voltage: 110V AC
Input Voltage: 220V AC
Input Voltage Range: 100V AC to 127V AC
Frequency: 50 Hz or 60 Hz
Power Consumption: 60 W Maximum
Power Source: Power Supply
Redundant Power Supply: Yes
Cisco WS-C3750-48TS-S Environmental Conditions

Temperature: 32 degrees F (0.0 degrees C) to 113 degrees F (45.0 degrees C) Operating
Temperature: -13 degrees F (-25.0 degrees C) to 158 degrees F (70.0 degrees C) Storage
Cisco WS-C3750-48TS-S Miscellaneous

Certifications & Standards:

• IEEE 802.1s

• IEEE 802.1w

• IEEE 802.1x

• IEEE 802.3ad

• IEEE 802.3x: full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports

• IEEE 802.1D: Spanning-Tree Protocol

• IEEE 802.1p: CoS Prioritization

• IEEE 802.1Q: VLAN

• IEEE 802.3: 10BASE-T specification

• IEEE 802.3u: 100BASE-TX specification

• IEEE 802.3ab: 1000BASE-T specification

• IEEE 802.3z: 1000BASE-X specification

• RMON I and II standards

Safety certifications:

• UL to UL 60950, Third Edition

• C-UL to CAN/CSA C22.2 No. 60950-00, Third Edition

• TUV/GS to EN 60950:2000

• CB to IEC 60950 with all country deviations

• NOM to NOM-019-SCFI

• CE Marking

Electromagnetic emissions certifications:

• FCC Part 15 Class A

• EN 55022: 1998 (CISPR22)

• EN 55024: 1998 (CISPR24)

• VCCI Class A

• AS/NZS 3548 Class A

• CE

• CNS 13438 Class A

• MIC

Telco:

• CLEI code

Management:

• BRIDGE-MIB

• CISCO-CDP-MIB

• CISCO-CLUSTER-MIB

• CISCO-CONF-MAN-MIB

• CISCO-ENTITY-FRU-CONTROL-MIB

• CISCO-ENVMON-MIB

• CISCO-FLASH-MIB

• CISCO-FTP-CLIENT-MIB

• CISCO-HSRP-MIB

• CISCO-HSRP-EXT-MIB

• CISCO-IGMP-FILTER-MIB

• CISCO-IMAGE-MIB

• CISCO-L2L3-INTERFACE-CONFIG-MIB

• CISCO-MAC-NOTIFICATION-MIB

• CISCO-MEMORY-POOL-MIB

• CISCO-PAGP-MIB

• CISCO-PING-MIB

• CISCO-PROCESS-MIB

• CISCO-RTTMON-MIB

• CISCO-STACK-MIB

• CISCO-STACKMAKER-MIB

• CISCO-STP-EXTENSIONS-MIB

• CISCO-SYSLOG-MIB

• CISCO-TCP-MIB

• CISCO-VLAN-IFTABLE-RELATIONSHIP-MIB

• CISCO-VLAN-MEMBERSHIP-MIB

• CISCO-VTP-MIB

• ENTITY-MIB

• ETHERLIKE-MIB

• IF-MIB

• IGMP-MIB

• IPMROUTE-MIB

• OLD-CISCO-CHASSIS-MIB

• OLD-CISCO-FLASH-MIB

• OLD-CISCO-INTERFACES-MIB

• OLD-CISCO-IP-MIB

• OLD-CISCO-SYS-MIB

• OLD-CISCO-TCP-MIB

• OLD-CISCO-TS-MIB

• OSPF-MIB (RFC 1253)

• PIM-MIB

• RFC1213-MIB

• RFC1253-MIB

• RMON-MIB

• RMON2-MIB

• SNMP-FRAMEWORK-MIB

• SNMP-MPD-MIB

• SNMP-NOTIFICATION-MIB

• SNMP-TARGET-MIB

• SNMPv2-MIB

• TCP-MIB

• UDP-MIB

Cisco WS-C3750-48TS-S Original Manufacturer Warranty

Standard Warranty: Lifetime Limited
Parts Warranty/Labor: 5 Year - Fan & Power Supply
Additional Warranty Information: In the event of discontinuance of product manufacture, Cisco warranty support is limited to five (5) years from the announcement of discontinuance.
Cisco WS-C3750-48TS-S General Information

Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Line: Catalyst
Product Series: 3750
Product Name: Catalyst 3750-48TS Ethernet Switch
Product Type: Ethernet Switch
Cisco WS-C3750-48TS-S Interfaces/Ports

Number of Ports: 48
Fast Ethernet Port: Yes
Interfaces/Ports: 48 x RJ-45 10/100Base-TX LAN
Interfaces/Ports: 2 x Stack
Interfaces/Ports: 1 x RJ-45 Console Management
Cisco WS-C3750-48TS-S Media & Performance

Connectivity Media: Category 4 UTP 10Base-T
Connectivity Media: Category 3 UTP 10Base-T
Connectivity Media: Category 5 UTP 10/100Base-TX
Performance: 32Gbps Backplane Speed
Performance: 38.7Mpps Stack Forwarding Rate for 64-byte Packet
Cisco WS-C3750-48TS-S Physical Characteristics

Dimensions: 1.73 Height x 17.5 Width x 11.83 Depth
Shipping Dimensions: 9 Height x 16 Width x 22 Depth
Weight: 9.1lb
Shipping Weight: 16 lb
